The 7812XC-AES8-3G is a Broadcast Quality Cross Converter that converts between common HD/SMPTE ST 292-1 video signals. The -3G versions support for common 3G/SMPTE ST 424 video signals. These modules support frame synchronization and external genlock inputs (card and frame reference) for video timing adjustments. The 7812XC series incorporates Mosquito Noise Reduction (MNR) and Block Artifact Reduction (BAR) in addition to motion adaptive spatial-temporal (3D) noise reduction. The 7812XC series also incorporates new de-interlacing technologies for superior resolution and artifact reduction. The 7812XC series supports broadcast quality scaling and offers both standard and user-defined ARC modes. AFD (SMPTE ST 2016) based steering of ARC modes and stamping AFD codes is fully supported. Transitions between AFD modes are frame-accurate/glitch-free. With the +F option, signals applied to PGM B IN can be keyed into image side panels. FILL inputs are frame synchronized so that pre-timing of FILL inputs is not required. With the +CF2G option, static or animated side panels can be stored locally and keyed into image side panels. Full broadcast quality color correction and detail enhancement processors are integrated into the 7812XC series. RGB-based color legalization is also supported. The 7812XC series supports 16 channels of embedded audio with audio delay automatically matching video delay. Additional audio delay is available. Full audio proc is supported including per-channel audio gain, channel swapping, and inversion controls. Surround sound to stereo (Lt/Rt or LoRo) down-mixing is supported. On -AES8 variants of the 7812XC series, 8x discrete AES inputs and outputs are supported in addition to advanced audio processes like stereo to 5.1 up-mixing (+UMX), Dolby® E/AC-3 Decoding (+DD), Dolby® E Encoding (+DEE), Dolby® AC3 Encoding (+AC3E) and IntelliGain Loudness Management (+IG). Any two Dolby® encode or decode functions may be integrated into a single card including dual decoders or dual encoders.
